PIPER CAMS camshafts 300º RACE Peugeot/Citroen 2.0L 16v XU10J4RS ( RFS )
PIPER CAMS camshafts 300º RACE Peugeot/Citroen 2.0L 16v XU10J4RS ( RFS )
Couldn't load pickup availability
Race camshaft – High performance 300° profile
A camshaft designed for competition use, with an aggressive 300° intake and exhaust profile . Designed to deliver optimal performance in the high tachometer range, ideal for tuned engines operating between 4,500 and 8,500 rpm . This profile improves cylinder filling and maximizes valve overlap for greater volumetric efficiency at high revs.
Technical specifications:
| Attribute | Worth |
|---|---|
| Guy | Race |
| Duration of admission | 300° |
| Escape duration | 300° |
| Power band | 4500–8500 rpm |
| Full intake lift | 104° |
| Complete exhaust lift | 106° |
| Intake valve lift | 12.19 mm |
| Exhaust valve lift | 12.19 mm |
| TDC – Intake lift | 4.62 mm |
| TDC – Exhaust Lift | 4.57 mm |
| Admission timing (ABDC / BTDC) | 46° / 74° |
| Exhaust timing (BBDC / ATDC) | 76° / 44° |
| Intake valve clearance | 0.20 mm |
| Exhaust valve clearance | 0.25 mm |
This camshaft is recommended exclusively for racing use. It requires modifications to the electronic management system, precise valve timing, and reinforced internal components to ensure maximum performance and reliability.
IT REQUIRES MACHINING THE CYLINDER HEAD SO THAT THE CAMS DO NOT TOUCH THEIR ROTATION IN THE CYLINDER HEAD
